Description

Engine
Model	3TNV88
Type	3-Cylinder Direct Injection Engine
Displacement (L)	1.642
Rated power (kW/rpm)	22.2/2400
Hydraulic System
Type	Variable Displacement Piston Pump
Rated Flow (L/min)	96.8
Digging Force
Arm Crowding Force (kN)	18.2
Bucket Digging Force (kN)	30.4
Travel System
Travel Speed (km/h)	2.4-4.4
Traction Force (kN)	–
Gradeability	30°
Swing System
Max. Swing Speed (r/min)	0-9
Brake Type	Mechanical Brake
Machine Specifications
Operating Weight (kg)	3800
Ground Pressure (kPa)	32
Bucket
Bucket Capacity (m³)	0.12
Fluid Capacities
Fuel Tank Capacity (L)	50
Cooling System Capacity (L)	7
Engine Oil Capacity (L)	6.7
Hydraulic Tank/System Capacity (L)	40/40
Dimensions
Overall Length (mm)	4880
Ground Contact Length (Transport) (mm)	3360
Overall Height (to Boom Top) (mm)	1880
Overall Width (mm)	1740
Overall Height (to Cab Top) (mm)	2550
Counterweight Ground Clearance (mm)	595
Minimum Ground Clearance (mm)	295
Tail Swing Radius (mm)	860
Track Length (mm)	2155
Track Gauge (mm)	1440
Track Width (mm)	1740
Standard Shoe Width (mm)	300
Swing Frame Width (mm)	1550
Distance from Swing Center to Rear End (mm)	860
Working Range
Max. Digging Height (mm)	4910
Max. Dumping Height (mm)	3545
Max. Digging Depth (mm)	3075
Max. Vertical Digging Depth (mm)	2640
Max. Digging Reach (mm)	5500
Max. Ground-Level Digging Reach (mm)	5345
Max. Dozer Blade Lift Height (mm)	375
Max. Dozer Blade Cutting Depth (mm)	370
Boom Left Swing Travel (mm)	550
Boom Right Swing Travel (mm)	800
